| Power Requirements | 208-240V, 3 amp, 50/60 Hz, 1 ph (NEMA 20 amp plug, L6-20P) |
| Air Supply Requirements | 100-175 psi (7-12 bar) |
| Approximate Air Consumption | 4 CFM (110 Liters/Minute) |
| Internet Recommendations | Hardwire or Wireless add on, 10+mbps up and down |
| Rim Width | 1.5 in to 20 in (38 mm to 508 mm) |
| ALU | 7.5 in to 38 in (191 mm to 965 mm) |
| Rim Diameter | 10 in to 30 in (254 mm to 762 mm) |
| Maximum Tire Diameter | 38 in (965 mm) |
| Maximum Tire Width | 20 in (508 mm) |
| Maximum Tire Weight | 135 lbs (68 kg) |
| Imbalance Resolution | 0.05 oz ( ± 1.0 g) |
| Placement Accuracy | 512 positions, ± 0.35° |
| Balancing Speed | 150 rpm |
| Motor | Programmable drive system and DC motor |
| Dimensions | 60.5 in (1536 mm) x 85 in (2159mm) x 32.75 in (832 mm) |
| Weight | 410 lbs (186 kg) |
