| Camera Connection | Ethernet cable (data and power) |
| Quick ID Sensor Dimensions | 8 x 8 x 6 |
| Quick ID Weight | 20 lbs |
| Camera Trigger | Quick Tread or Quick Check system |
| License Plate Location | Front or rear of the vehicle |
| Quick ID Mounting Positions | Center, Off-center, Indoor or Outdoor |
| License to VIN service | Authorized CARFAX EULA on file |
| Light Requirement | 400 lux or greater at point of image capture |
| Wireless Network Module | Standard |
| Vehicle Speed | 2 to 8 mph |
| Quick Check Cabinet Shipping Weight | 290 lbs. |
| Monitor Size | 24" Widescreen LCD |
| HunterNet® | 3 years free access for 1 user |
| Quick Check Software | Standard |
| Wireless Remote | Standard |
| VIN Barcode Reader | Standard |
| Compact Cabinet Dimensions | 32"W x 65"H x 23"D |
| Power Line Filter | Standard |
| Real-time Specs (delivered by web) | Web Specs® |
| Power Requirements | 115/230V, 15 Amp 50/60 Hz 1 Ph |
| Vehicle Specifications (30 plus years) | 2 years free updates |
| Processor | 3.06 GHz Intel® Core i3 - 3.1GHz (or greater) |
| Hard Drive | 120 GB Solid State Hard Drive (or greater) |
| Operating System | Windows® 7 - 64 bit |
| DVD-RW/CD-RW Drive | Standard |
| Memory | 4 GB of DDR3 SDRAM |
| Maximum Ethernet Length | 328 ft. |
| Internet Connectivity | 10 MBps or greater, wired connection recommended |
| Printer | Color Ink Jet Printer |
| QC Alignment Printout | Thousands of available options |
| Quick Tread Shipping Weight | 530 lbs. |
| Air Supply Requirements (SI Units) | 90-150 P.S.I (6.2-10.3 bar) |
| Pedestal Location | 36 - 96 in. form nearest QT1 edge |
